Standard Features
- Resolution: 300, 600 dpi (11.811, 23.622 dots per mm) for the Sleek (Hermes +2); 203, 300, 600 dpi (7.99, 11.811, 23.622 dots per mm) for the Universal (Hermes +4) model; 203, 300 dpi (7.99, 11.811 dots per mm) for the Universal (Hermes +4.3) model and the Wide (Hermes +6) model
- Print width up to 54.2, 57 dpi (2.134, 2.244") for the Hermes +2; 104, 105.6, 105.6 mm (4.094, 4.157, 4.157") for the Hermes +4 and 104, 108.4 mm (4.094, 4.268") for the Hermes +4.3; and 168, 162.6 (6.614, 6.402") for the Hermes +6
- Print speed up to 150, 100 mm (5.906, 3.937") per second for the Hermes +2; 250, 250, 100 mm (9.842, 3.937") per second for the Hermes +4; 250 mm (9.842") for the Hermes +4.3; and 200, 200 mm (7.874") per second for the Hermes +6
- 64 MB RAM Memory; 8 IFFS Flash
- Slot for Compact Flash Memory card
More Standard Features
- Label gap sensor
- Real-time clock, printout of date and time
- USB 2.0 high speed slave for PC connection interface
- LCD graphic display operation panel capable of 4 lines of text, 20 characters per line
- Gap sensor for leading edge of the label or punching marks and end of material, and a reflective sensor at the bottom for printing marks
- Jscript viewer is embedded to support native programming. The designer user interface and JScript code are synchronized in real-time. Special functions like Database Connector or barcode testers are easily integrated.
- Windows driver 32 / 64 bit certified for Windows Vista (Server 2003); Windows 7 (Server 2008); Windows 8 (Server 2008 R2); Windows 8.1 (Server 2012); and Windows 10 (Server 2012 R2)
- Extensive status printout includes information on setting, e. g. print length counter, runtime counter etc. Request machine status via software command. Detailed status messages are on the display, e. g. network error – no link, barcode error, etc.
Printer Specifications
Resolution: 300, 600 dpi (11.811, 23.622 dots per mm) for Sleek (Hermes +2)
203, 300, 600 dpi (7.99, 11.811, 23.622 dots per mm) for Universal (Hermes +4)
203, 300 dpi (7.99, 11.811 dots per mm) for Universal (Hermes +4.3), Wide (Hermes +6)
Memory: 64 MB RAM, 8 IFFS Flash
Print width up to 54.2, 57 (2.134, 2.244") for the Hermes +2; 104, 105.6, 105.6 mm (4.094, 4.157, 4.157") for the Hermes +4 and 104, 108.4 mm (4.094, 4.268") for the Hermes +4.3; and 168, 162.6 (6.614, 6.402") for the Hermes +6
Print speed:
- Hermes +2 – up to 150, 100 mm (5.906, 3.937") per second
- Hermes +4 – up to 250, 100 mm (9.842, 3.937") per second
- Hermes +4.3 – up to 250 mm (9.842") per second
- Hermes +6 – up to 200 mm (7.874") per second
Media Characteristics
Maximum label and liner width: 4 mm (.158") to 58 mm (2.283") for Hermes +2
10 mm (.394") to 114 mm (4.488") for Hermes +4, +4.3
50 mm (1.969") to 174 mm (6.850") for Hermes +6
Media thickness: 0.055 mm (0.002") to .35 mm (0.014") per weight of 60 g (.132 lb.) to 160 g (.353 lb.)
Media types: Labels, including paper and plastics such as PET, PE, PP, PVC, PU, acrylate, and PI
Ribbon Characteristics
- Ink – outside or inside
- Roll diameter up to 80 mm (3.149")
- Core diameter 25 mm (0.984")
- Ribbon length variable up 500 m (1640.42')
- Width up to 60 mm (2.362") for Hermes +2; 114 mm (4.488") for Hermes+ 4 and +4.3; 165 mm (6.496") for Hermes +6
- Optional ribbon saver.
Operating Data
Power supply – 100 - 240 V ~ 50 / 60 Hz, PFC
Energy consumption – maximum 300 W
Temperature / Humidity:
- Operation: + 5 - 40°C (41 – 104 °F) / 10 - 85% not condensing
- Storage: + 0 - 60°C (32 – 140 °F) / 20 - 85% not condensing
- Transport: – 25 - 60°C (77 – 140 °F) / 20 - 85% not condensing
Approvals – CE, FCC class A, CB, CCC, and UL
Physical Characteristics
Width:
- Hermes +2: 207 mm (8.15")
- Hermes +4 and +4.3: 260 mm (10.24")
- Hermes +6: 320 mm (12.6")
Height: 400 mm (15.748") for Label roll Ø 205 mm and 538 mm (21.181") Label roll Ø 305 mm
Depth: 400 mm (15.748") for Label roll Ø 205 mm and 518 mm (20.394") Label roll Ø 305 mm
Weight:
- Hermes 2+: 15 kg (33.069 lb.)
- Hermes +4 and +4.3: 16 kg (35.274 lb.)
- Hermes +6: 20 kg (44.092 lb.) (Hermes +6)
Mounting Foot Orientation: Right, Left
Related Products
Accessories
- 1 Cover
- 2 Interface External Operation Panel
- 3 Standard Keyboard
- 4 Memory Card
- 5 Product sensor to start 25 pin
- 6 Product sensor 3-pin
- 7 Interface connector SUB D plug
- 8 Warning light
- 9 Circular connector
- 10 Extended peel-off plate +10 mm
- 11 Margin stop
Interfaces
- 1 Interface Centronics
- 2 RS422/RS485
- 3 Label selection box – I/O box
- 4 I/O Interface adaptor
Connecting Cable
- 1 Connecting cable RS232 C
- 2 Patch cable CAT5e
Extra Hermes+ /Hermes C Applicators
- 13 – Blow tube
- 14 – Air pressure regulation unit
- 15 – Air pressure regulation unit with main valve
- 16 – Air pressure regulation unit with additional shutoff valve
- 17 – Compressed air regulator
Mounting Aids for Hermes+
- 1 – Adaptor Plate
- 2 – Profile
- 3 – Base Plate
- 4 – Mounting Plate
- 5 – Bracket
- 6 – Clamped joint for profile 50 x 50 mm
- 7 – Flanged joint for profile 50 x 50 mm
- 8 – Floor stand 1601 Hermes+
- 9 – Floor stand 1602 Hermes+
Label Software
- cablabel® S3 Lite (free)
- cablabel® S3 Pro
- cablabel® S3 Print
- cablabel® S3 Demo (free)
Programming Languages
- Direct programming with Jscript
- abc-Basic Compiler
- Database Connector
- Replace files and Integration in SAP R/3
Barcodes/Symbologies
Linear barcodes:
- Code 39, Code 93 Interleaved 2 / 5
- Code 39 Full ASCII Ident and lead code of
- Code 128 A, B, C Deutsche Post AG
- EAN 8, 13 Codabar
- EAN / UPC Appendix 5 Plessey
- FIM Postnet
- EAN / UCC 128 JAN 8, 13
- EAN / UPC Appendix 2 MSI
- HIBC RSS 14 UPC A, E, E0
2-dimensional barcodes: Aztec, Codablock F, Data Matrix, EAN-Datamatrix, Micro PDF 417, PDF 417, UPS Maxicode, QR-Code, RSS 14 truncated, limited, stacked and stacked omnidirectional, GS1 Data Bar
All codes variable in height, module width and ratio. Orientation 0°, 90°, 180°, 270°. Option includes check digit, printed characters and start/stop code; depends on the code type.
Fonts and Graphics
- Fonts: 5 Bitmap fonts incl. OCR-A, OCR-B and 3 Vector fonts Swiss 721, Swiss 721 Bold and Monospace 821 are available internally, and loadable TrueType fonts.
- Character sets: Windows 1250 to 1257, WinOEM 720, UTF-8, Macintosh Roman, EBC DIC 500, ISO 8859-1 to -10 and -13 to -16, DOS 437, 737, 775, 850, 852, 857, 862, 864, 866, 869, DEC MCS, K0I8-R. All West and East European Latin, Cyrillic, Greek, Hebrew and Arabic characters supported. Thai and Chinese supported.
- Bitmap fonts: Size of width and height 1 – 3 mm; Zoom 2-10; Orientation: 0°, 90°, 180°, and 270°
- *TrueType fonts: width and height 0.9 – 128 mm; variable zoom; Orientation 360° in 1° steps
- Font formats: Bold, italic, negative, underlined, outline, inverse, depending on character fonts
- Font width: variable
- Graphic elements: Line, arrow, box, circle, ellipse, including filled and filled with fading
- Graphic formats: PCX, MAC, GIF, IMG, BMP, TIF, PNG
